BR 20 Amp 120/240 Volts Single Pole Circuit Breaker Contractor (Pack of 10) - 9101959

Highlights

• Primary function of a circuit breaker is to protect the wire from overheating (overload) and fault currents (short circuit)
• Amperage rating: 20A
• Single pole 1 in. wide breaker
• Trips to center position - must turn off then turn back on
• For use in type BR load centers
• Type BR breakers are UL approved genuine replacement breakers for load centers made by Westinghouse, Challenger and Bryant
• Interrupt rating - 10 kAIC
• Voltage rating is 120/240V
• Wire size - #14-4 AWG Cu/Al at 60°C or 75°C
• Gauge / number of wires with ground - 14/2
